RFID UHF Gain 8dBi Antenna 865-867/902-928 MHz External Antenna 5M N-Female

SKU
HYANT8DB
Special Price US$30.24 Regular Price US$33.60
In stock
Overview

RFID UHF Gain 8dBi Antenna 865-867/902-928 MHz External Antenna 5M N-Female

Parameter:

  • Frequency Range :902-928MHz (Compatible 840-960MHz)
  • Gain :8dBi
  • Detection range from 0 - 5 metre
  • Horizontal Beamwidth: 68°
  • Vertical Beamwidth: 68°
  • F/B Ratio:≥20dB
  • VSWR:≤1.3
  • Nominal Impedance:50Ω
  • Polarization :Circularly polarized
  • Maximum Power:50W
  • Connector:N (Female)
  • Dimensions:225×225×35mm
  • Weight :1.3kg
  • Installation :Embrace rod installation (optional clip code)
  • Mounting Mast Diameter : φ40~50mm
  • High performance, high gain, low standing wave;
  • Light weight, small volume, low profile;
  • Anticorrosive ability

 NOTE:

1. 902MHz~928MHz (USA standard) The antenna application of the UHF RFID system.
2. Compatible with the Europe standard(865~868MHz) and China standard(920~925MHz) ect.
3. Can be applied to passive UHF RFID commercial system such as warehousing, logistics, inventory ect.
4. Can be used with the reader of Impinj R2000, Austriamicrosystems AS3992 or PR9000 ect.





More Information
Description

Parameter:

  • Frequency Range :902-928MHz (Compatible 840-960MHz)
  • Gain :8dBi
  • Detection range from 0 - 5 metre
  • Horizontal Beamwidth: 68°
  • Vertical Beamwidth: 68°
  • F/B Ratio:≥20dB
  • VSWR:≤1.3
  • Nominal Impedance:50Ω
  • Polarization :Circularly polarized
  • Maximum Power:50W
  • Connector:N (Female)
  • Dimensions:225×225×35mm
  • Weight :1.3kg
  • Installation :Embrace rod installation (optional clip code)
  • Mounting Mast Diameter : φ40~50mm
  • High performance, high gain, low standing wave;
  • Light weight, small volume, low profile;
  • Anticorrosive ability

 NOTE:

1. 902MHz~928MHz (USA standard) The antenna application of the UHF RFID system.
2. Compatible with the Europe standard(865~868MHz) and China standard(920~925MHz) ect.
3. Can be applied to passive UHF RFID commercial system such as warehousing, logistics, inventory ect.
4. Can be used with the reader of Impinj R2000, Austriamicrosystems AS3992 or PR9000 ect.
