Good Quality ZK Access Control Card Reader Wiegand34 MF Card IC Card Reader IP64 Waterproof Smart Ca
Good Quality ZK Access Control Card Reader Wiegand34 MF Card IC Card Reader IP64 Waterproof Smart Card Reader With Keypad KR602M...
Function:
• Read range of up to 10cm for RFID card and 5cm for Mifare card
• External LED control
• External Buzzer Control
• Indoor/Outdoor operation
• Solid Epoxy potted
• Waterproof IP64
• Reverse Polarity Protection
Card reader:
| Output Interface | Standard Wiegand34 |
| Operating Frequency | 13.56MHZ |
| Reader Card | IC Card |
| Transmitting Distance | WG<100M |
| Proximity Range | KRxxx-E: Up to 10CM • KRxxx-M: Up to 5CM |
| Power/Current | DC 6-14V / Max.70mA |
| Static Power Supply | <70mA |
| Temperature | -10°C~65°C |
| Relative Humidity | 10%-90% |
| Recognition Speed | <=200ms |
| Input Port | • External LED Control • External Buzzer Control |
| Communication distance | 100m |
| Communication way | Real time |
| LED | Red and Green LEDs |
| Beeper | Yes |
| Color | Black Color |
| Material | ABS+PVC Material (Black Resin for Water-Proof Function) |
| Waterproof | • KR600-E/M: IP65 • KR601-E/M: IP65 • KR602-E/M: IP64 |
| Dimension | 86*86*18(mm) |
| Package | 100pcs per carton. Carton Size: 43.5*56*23(cm) |
