ANSI/ISO Standard ATM Magnetic Card Access Control

ANSI/ISO standard ATM Magnetic Card Access Control
Main Characteristic:
Magnetic  head  meets the  ANSi/ISO standard.
There is no  card capacity limitation
The metal outer cover of alloy of zinc is sturdy and duable, position fixed with stable screws.
unique anti-interference  design to  fit a variety of environment installation.
Adopt import the alloy magnetic head, wear-resisting,high sensitivity, support different card feeding speed.
Characterized  with large capacity of  lock output  module, it can link with various electric locks directly.
Dry contact signal output, can be linked with various autodoor,access controller and electric lock simultaneously.
With time difference setting to ensure the autodoor runs smoothly.
Power supply:DC12V
Output current of electric lock: 3A( 12v)
Static current:22MA
Operation current:40MA
Maintain open time: 1- 10S adjustable
Time difference for unlocking and open door: 0.5S
Magnetic card standard: ISO7811-7815
Card feeding speed:10-120cm/s
Operation temperature: -42-45degree
Environment humidity:10~90%RH
Dimension:138mm(L)x56mm(W)x32mm(H)
Weight:400g
Model NO. : NT-M2000 Magnetic Card Access Control
Maintain Open Time : 1- 10s Adjustable
Magnetic Card Standard : ISO7811-7815
Time for Unlocking and Open Door : 0.5s
Card Feeding Speed : 10-120cm/S
Operation Temperature : -42-45degree
Environment Humidity : 10~90%Rh
Transport Package : Neutral Packing
Specification : CE
Trademark : Nordson
Origin : Guangdong
HS Code : 123456
Production Capacity : 10000PCS/Per Month
