Hands-Free Human Body High-Temperature Alarm Device for Office and Entrance

Model : BO-01

• Sensor : High performance laser sensor (transceiver type)
• Performance : accuracy: ±1cm
• Wavelength : 5.5 μm Longpass Filters
• Forehead temperature measurement range : 35~43ºC(No wind)
• Accuracy : ±0.3ºC
• Distance : 1-50cm
• Get the temperature ways : IIC
• Thermopile resistance : 170±20%KΩ,Conditions:temp=25ºC
• Noise voltage : 42±2nV/Hz1/2,Conditions: temp=25ºC
• Responsibility : 60±10V/W,Conditions: 500K,5.5μm,long-wave
• Time constant : 16±4ms
• Detection : (0.60±0.8) E08cmHz1/2/W     Conditions: 500K, 1Hz
• NTC : 100 ± 1%KΩ    Conditions: 25ºC
• NTC BETA : 3950 ± 1%K     Conditions: 25ºC/50ºC
• Dry cell/Battery : 5AA*4
• USB interface : Powered via USB (without battery)
• Storage temperature : -20±60ºC
• Environment temperature : 0-40ºC
• Power consumption : ≤ 0.2W, Working current≤ 40mA
• Size : 110mm(Length)*90mm(Width)*30mm(Height)
