Access control locks electric locks EML Electromagnetic Lock EM Lock Access Controller 280KG single door magnetic lock light

Product Name:280Kg Single Door Magnetic Lock
Usage:Access control system output for external devices , suction force generated by DC12V voltage path and is widely used in all kinds of doors tools, suitable for installation in steel doors, fire doors , doors , etc.
Features:

• 280kg (600Lbs) static linear tension
• Factory set to 12VDC voltage standard
• Built-in reverse current protection device (MOV)
• Suitable for wooden doors, glass doors, metal doors, fire doors
• Anti residual magnetism design, selection of materials imported iron
• The shell is made of high-strength aluminum alloy, Anodized
• Magnetic locks no mechanical failure, complete with electromagnetic suction work
• Increase the electromagnetic suction , professional design, insulated double lock
• Products certified by China MA

Product parameters :

• Lock Size : Length Width 250x height 48x 25 (mm)
• Blister Dimensions: Length Width 180x height 38x 11 (mm)
• Maximum tension : 280kg (600Lbs) straight Rally
• Input voltage : DC12V
• Current : 12V/450mA
• Applicable : Wooden door , glass doors, metal doors, fire doors
• Surface temperature: +20 ° below ambient temperature within
• Temperature : -10 ~ +55 ° (14-131F)
• Suitable Humidity : 0 ~ 95% ( relative humidity )
• Shell: Anodized aluminum
• Lock handle : Environmental plating
• Blister Treatment: environmental plating
• Weight : 2kg
