RS232 series converters UT-216 to 485422 active lightning protection switch

This shop all baby pictures are real shooting, and all baby pictures are encrypted for security, to as close to the baby picture, can contact our customer service. May the individual baby pictures because lighting effects, and the physical presence of the smaller color difference, both both please understand!Thank you very much!

Can the dojo. Dojo.provide formal machine invoice

Home furnishings, anti - counterfeit labels.













   UT - 216 interface converter. Compatible with RS - 232 c. RS - 422. The RS - 485 standard, can be an RS - 232 signal is converted into a balanced differential RS - 422 or RS - 485

No.,Built - in fastThe transient voltage suppression protectorThis protector is designed to protect the RS - 422 / RS - 485 interface,Using today 's advanced TVS (TRANSIENT VOLTAGE

The transient voltage SUPPERSSOR)suppressorIn the high impedance state, under normal circumstances, TVS tube, the the when TVS tube ends through instant high energy impact, it can "bringing the two at high speed

The impedance is reduced, to absorb a large electricityAt the ends of the flow, thus its voltage clamp down on a predetermined value, to protect the back of the circuit componentsDon 't damage by transient high pressure impact.

This protectorCan effectively inhibit the 20Dojo. Dojo.provide (20), each line from surge protection of power of 600 w, as well as a variety of having on the surge voltage and transient

Overpressure and tiny electrode capacitance RS - is guaranteed422 / RS - 485 interface of high speed transmission. The RS - 232 interface end by a female DB9 connector of The head and compatible with The RS - 232 - c standard

Interface is linked together, the RS - 422. The RS - 485 side even through the DB9 male headAdapter connection. Inside the converterWith zero delay the transmit - and receive automatically, the automatic I/O circuit control data flow

Direction, without any handshake signals (to as RTS, DTR, etc.), do not need to jump the lineBuy the to full - duplex (RS - 422). Half duplex mode conversion (RS - 485), plug-in and play. Make sure

Suitable for all the existing communication software and the hardware interface, no need to on the RS - 232Make any software modification works.

UT - 216 interface converter for point to point. The Dojo. Dojo.provide reliable connection point to multipoint communication, point to multipoint 32 each converter can be allowed to connect the RS - 422 or RS - 485

The device,The Data communication rate from 300 to 115.2 Kbps, have The power indicator light and Data traffic light are a fault condition. Support The communication methods have The RS - 232 to RS - 422.

The RS - 232 to RS - 485.

The performance parameters:

S compatible with RS - 232, RS - 485 TIA/EIA RS - 422 standard

S to send/receive data automatically, without external flow control signal (RTS)

S the communication rate: 300 BPS - 115.2 Kbps

32 S able to connect the RS - 485 or RS - 422 interface equipment

S communication short: 1200 m (9600 BPS)

S power supply and data traffic towns, the point of failure can be detected

S works: asynchronous half - duplex (RS - 485) or asynchronous full - duplex (RS - 422) and general, without having to jump line Settings

S 485/422 RS - 600 w per line from protection, and prevent total interference

S electrical interface: DB9 groove to the DB9 pin type and RJ 45 connector

S transmission medium: the twisted pair or shielded wire

S shape size: 97 mm * 65 mm * 22 mm

S the use of the environment: 25 ° to 70 °, the relative humidity of 5% to 95%

S applies to all communications, informs by software, plug-in and play

S support DOS/Linux to WIN95 / WIN98 / WIN2000 / NT/XP, etc
