Stable Holding Force 600kg/1200 Lbs DC12V or DC24V Fail-Safe Electromagnetic Lock with Signal Door

Stable holding force 600kg/1200 Lbs DC12V or DC24V Fail-safe Electromagnetic lock with signal Door
With LED and signal output
Voltage:DC12V or DC24V
Waterproof IP65 Customization Available
Holding Force: 600kg(1200Lbs)
Lock Size: 266L*67W*39H(mm)
Armature Plate:185L*57W*13H(mm)
Current Draw: 12V/500mA 24V/250mA
No residual magnetism, no mechanical damage 90 degrees open for all kinds of doors with frame
With Buzzer Customization Available
Weight: 4.5kg
Packaging & Shipping
Packaging: Neutral Package.
Shipping:    Small quantity within 1-5 work days after receipt of remittance, large quantity within 14 work days after receipt of remittance.
Our Services
For the non-human factors of product quality issues, NORDSON offer three-year warranty services for electromagnetic lock; 3-year warranty for access control panel, electric bolt and electric strike; 1 year warranty for exit button, bracket, and power supply. The customers should take charge of the material and the maintain fees if the product damaged under other conditions.
Model NO. : NE-600S(LED) Electromagnetic lock
Surface Finish for Magnet : Zinc Plated
Surface Finish for Armature Plate : Zinc Plated
Suitable for : Wooden & Aluminum & Glass & Fireproof &Metal
Magnets Dimensions(L X W X D) : 265lx71wx40h(mm)
Armature Plate Dimensions(L X W X D) : 185lx60wx13h(mm)
Weight in Kg : 4.5kg
Transport Package : Neutral Packing
Specification : CE, ROSH
Trademark : Nordson
Origin : Shenzhen, China
HS Code : 123456
Production Capacity : 4.5kg
