7pcs/Lot,NTAG213,NFC tags/RFID adhesive label/sticker,compatible with all nfc products dia 30mm
-
-
7pcs/Lot NTAG213 NFC tags RFID adhesive label sticker PVC compatible with all nfc products size dia 30mm
-
Sticker Specifications:
- Shielded sticker; can be applied on RF-interfering surfaces such as cellphone batteries
- Adhesive backing
NFC Chip Specifications:
- NFC Chip Type: NTAG213
- Full compliance to the NFC Forum Tag 2 Type technical specification
- 168 bytes of total memory, divided in 42 pages (4 bytes each)
- 144 bytes of user R/W memory area, divided in 36 pages (4 bytes each)
- Rewrite Endurance: 10,000 cycles
- 16-bit counter
- Lockable: yes (can be made read only)
- Operating Frequency: 13.56 MHz
- Operating Range < 2cm (depends on device)
- Compatible with NFC enabled smartphones
- Works with the new Nexus 4 phone and Nexus 10 Tablet
Security & Anti-collision:
-
- Anti-collision function according to ISO/IEC 14443 allows to operate more than one sticker in the field simultaneously
- Anti-cloning support by unique 7-byte serial number for each device
- 32-bit user definable One-Time Programmable (OTP) area
- Field programmable read-only locking function per page for first 512 bits
- Read-only locking per block for rest of memory
Specifications
Label/chip Type
NTAG 213
Operating Frequency
13.56 MHz
Capacity
168 bytes EEPROM (144 bytes available)
Tested Read Range
0 - 100 mm depending on the power provided by the reader
Multi-Detection
Yes
Size
dia 30mm
Material
PVC / adhesive sticker
Protocol:
ISO14443A
Environmental Specification
Shelf Life 5 Years
Recommended: -25C to +50C
Storage Condition: 20% to 90%RH
Operating Temp: -40C to +65C
Read/write Times:
100000 times
Color
White PVC
Application:
Public Transportation, Access management, E-tickets, Logistic and supply management, Production manufacturing and assembly, Windshield label, Document tracking, Laundry management, Library management, Animal identity and so on
thickness with adhesive
0.5mm
Package include
7 pcs/lot NFC sticker/tags NTAG 213, dia 30mm Blank(no printing) PVC material
-
-
Product Name | 7pcs/Lot,NTAG213,NFC tags/RFID adhesive label/sticker,compatible with all nfc products dia 30mm | ||||||||||||||||||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Description |
|
||||||||||||||||||||||||||||||||
SKU | 32759290247 | ||||||||||||||||||||||||||||||||
Weight | 0.010000 | ||||||||||||||||||||||||||||||||
selling_potential | 3 | ||||||||||||||||||||||||||||||||
With Built-in Battery | No | ||||||||||||||||||||||||||||||||
Condition | New |
