Escam Snail QD500 onvif indoor outdoor camera p2p hd security camera privacy masking and night vision fuction camera

Details

01--QD500 1 02--QD500-02 + 3.6mm 03--QD500 03 04--QD500-04 05--QD500-05 06--QD500-07 CMOS H.264 07--QD500--8 HD 720P 08--DWDR 09--P2P 10--QRCode 11--Cloud Technology 12--Onvif 13--IE 14--CMS 15-- 16--

<

Camera
Key Features
>1/4” 1Megapixel progressive scan CMOS
>H.264 dual-stream encoding
>Max 25/30fps@720P(1280×720)
>DWDR, Day/Night(ICR), 2DNR, AWB, AGC, BLC
>Multiple network monitoring: Web viewer, CMS
>3.6mm fixed lens
>Max. IR LEDs Length 10m
>DC12V 1A

Model		QD500
Camera
Image Sensor		1/4” 1Megapixel progressive scan CMOS
Effective Pixels		1280(H)x720(V)
Scanning System		Progressive
Electronic Shutter Speed		Auto/Manual 1/3(4)~1/10000
Min. Illumination		Color: 0. 1Lux/F1.2, B/W: 0.01Lux/F1.2,0Lux (IR on)
S/N Ratio		More than 50dB
Video Output		N/A
Camera Features
Max. IR LEDs Length		10m
Day/Night		Auto(ICR) / Color / B/W
Backlight Compensation		BLC/ HLC/ DWDR
White Balance		Auto/Manual
Gain Control		Auto/Manual
Noise Reduction		3D
Privacy Masking		Up to 4 areas
Lens
Focal Length		3.6mm
Max Aperture		F1.8
Focus Control		Manual
Angle of View		H: 70°
Lens Type		Fixed lens
Mount Type		Board-in Type
Video
Compression		H.264
Resolution		720P(1280×720)/ D1(704×576/704×480) /CIF(352×288/352×240)
Frame Rate	Main Stream	720P(1 ~ 25fps)
	Sub Stream	D1/CIF(1 ~ 25fps)
Bit Rate		H.264: 16K ~ 4096Kbps
Audio
Compression		N/A
Interface		N/A
Network
Ethernet		RJ-45 (10/100Base-T)
Wi-Fi		N/A
Protocol		IPv4, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP
ONVIF		ONVIF Profile S
Max. User Access		10 users
Smart Phone		iPhone, iPad, Android
P2P		iPhone, Android Mobile App
Auxiliary Interface
Memory Slot		N/A
RS485		N/A
Alarm		N/A
PIR Sensor Range		N/A
General
Power Supply		DC12V 1A
POE		N/A
Power Consumption		<4W
Working Environment		-30°C~+60°C, Less than 95%RH
Ingress Protection		IP66
Vandal Resistance		N/A
Dimensions		Φ123mm x82mm
Weight		0.3Kg
Package Dimensions		140mm x140mm x110mm
Package Weight		0.41Kg
Approvals		CE FCC RoHS

';
