Flash light Automatic reading waterproof 125KHZ RFID Card active guard tour guard patrol system + 1

This order:

1*patrol

1*USB cable

1*box

10*125KHZ point

2*Staff RFID Tags

1*CD(English software)



I. Introduction

   The inspection system consists of a sensing patrol stick , USB communication dedicated line , patrolling points and software components. Patrol point there is an import lasered 8 hexadecimal encoding information sensing points, each sensing point numbers globally unique. Patrols will be encoded with different points placed at the sensing point inspection equipment or lines , and the coding and the corresponding place in the computer set up . Patrol officers wore patrol stick , stick in the inspection process using patrol near Patrol Point 5-10CM. Vibration and light tips when working , will read the time and place of rods stored in the patrol , officers will patrol the stick into the newsletter dedicated data lines connected to the computer through the computer application software will patrol inspection data stick into the computer archive . Readily available to managers for analysis, processing , statistics, production reports, giving managers a scientific and accurate assessment basis .

Second, the system equipment performance profile

1 , induction Patrol machine 101U

Technical parameters:

Waterproof:IP55

Reader mode : non-contact

Communication : USB

Store records : 100000

Induction distance : 0 ~ 6cm, no blind spots

Power supply: 3.7V rechargeable lithium battery ( 18650 )

Size : L160 × 35 mm

Weight: 160g
