HF tamperproof protection wet inlay
SKU
HFtamperproofwetinlay
- Part-Name： HF tamperproof wet inlay
- Part-Number： IVF- L602828A
- Antenna：IVF-TY02416A
- Antenna dimension: 24 X16mm (±0.2mm)
- Final Dimension: 28X28mm(±0.5mm)
- Antenna skip distance: 32.0±0.4mm
- Antenna margin: 3.5±1.0mm
- Width of the Tape: 31.0±1.0 mm
- Antenna number /square: 900 pcs
Parameter specifications:
- Substrate Material: Polyester Film（PET ）
- The Antenna Material : Aluminum Etching
- Surface Material : Polyester Film（PET ）
- Characteristics: theFlexible Transparency Label
- Product Attribute : Disposable，Prevent Heat Transfer
- Operating Frequency : 13.0MHZ ～14.5MHZ
- Supported Protocol : ISO/IEC14443-A
- Chip IC : FJ8004 (other compatible chips option)
- MEMORY & SECURITY : 512bit
- Operating Mode : Inventory Read or Write
- Reading Distance : ≥1CM（Reader：Desktop Reader IVF-RH11）
- Programming Cycle : 100,000 cycles
- Personalized Coding : Supporting multiple data structure of insideand outside combinatorial encoding（canbe synchronous and offline encoding）；Supportingpersonalized key code
Environmental parameters:
- Operating Temperature: -25℃～75℃
- Storage Temperature: 0℃～25℃
- Packing :
- Core Diameter : 76.2mm (3inch)
- Volume Number: 3000～5000PCS（According to Actual Demand）
- The Roll Direction: theSurface or Printing Facing out (up)
- Packing Material: Antistatic PE + Bubble Pad + AntistaticBag
- + Paper Carton/Box
| SKU | HFtamperproofwetinlay |
|---|---|
| Weight | 0.001000 |
| Customizable | No |
| With Built-in Battery | No |
| Minimum Order Quantity | No |
| Description |
Parameter specifications:
Environmental parameters:
|
