Portable Bluetooth+USB UHF RFID reader card reader card issuer Desktop R500 program Long Range 2M
Portable Bluetooth UHF RFID reader card reader card issuer uses R500 program Long Range 2M
TheUHF Bluetooth portable reader, Using Impinj R500 (or R2000 at extra cost)Program design, has a good multi- label processing capabilities , anti-jamming performance, built-3dBiCeramic antenna gain , read a single tag distance up2m / 3.5m;Intensive multi-tag read performance, greater than can be achieved200tags / sTag identification rate ;Bluetooth connectivity,USBConnect a variety of connections, providing full-featuredSDKDevelopment kits and interfaces,Easy andRFIDSoftware integration ;Use carrier cancellation technology , read the label better accuracy and wider ;To capture reliable data and enhanced noise suppression ;Precision return signal strength(RSSI); Due to the coherent receiver architecture and the introduction of the carrier cancellation ,RSSIMore stable and reliable , better read performance. Communication with the device via a Bluetooth connection , the equipment for the control , the device will read back the label information is returned directly to the mobile terminal , easy to use and efficient and effective operation of the device control is transferred to the most current mainstream mobile terminal . It can be widely used in small logistics inventory , field asset tracking management , warehouse management, desktop card, planting tracking management.
Note : This Bluetooth reader prices to customer needs, configure the different modules of different factors , please inform the customer demand , customer service will give the most professional answer and offer.
Specification:
- Support Agreement :EPCglobal Class1 Gen2 ISO18000-6C
- Operating frequency: standard configurationISM902-928MHz, Customizable other bands
- Work: a broad-spectrum frequency hopping(FHSS)Or fixed frequency set by software
- RF Power :0-30dBm (1W), Software adjustable
- Multi-tag read :50 tags / s @ SF-P8051,200tags / s @ SF-P8201
- Communication Interface: Bluetooth,MicroUSB (VCOMVirtual Serial Port)
- Read Range :2m @ SF-P8051,3.5m@SF-P8201 (Standard9662White card test)
- Reader Tip: buzzer, lamp
- Antenna:3dBiCeramic antenna
- Power supply: Built-in2600mAhLithium Battery
- Size :95 * 75 * 22 mm
- Working temperature:--30°~ 60°
- Storage temperature :- 40°~ 85°
- Development Kit : ProvidesSDKDevelopment kits,APIApplication routines
| Description |
TheUHF Bluetooth portable reader, Using Impinj R500 (or R2000 at extra cost)Program design, has a good multi- label processing capabilities , anti-jamming performance, built-3dBiCeramic antenna gain , read a single tag distance up2m / 3.5m;Intensive multi-tag read performance, greater than can be achieved200tags / sTag identification rate ;Bluetooth connectivity,USBConnect a variety of connections, providing full-featuredSDKDevelopment kits and interfaces,Easy andRFIDSoftware integration ;Use carrier cancellation technology , read the label better accuracy and wider ;To capture reliable data and enhanced noise suppression ;Precision return signal strength(RSSI); Due to the coherent receiver architecture and the introduction of the carrier cancellation ,RSSIMore stable and reliable , better read performance. Communication with the device via a Bluetooth connection , the equipment for the control , the device will read back the label information is returned directly to the mobile terminal , easy to use and efficient and effective operation of the device control is transferred to the most current mainstream mobile terminal . It can be widely used in small logistics inventory , field asset tracking management , warehouse management, desktop card, planting tracking management. Note : This Bluetooth reader prices to customer needs, configure the different modules of different factors , please inform the customer demand , customer service will give the most professional answer and offer.
Specification:
|
|---|---|
| SKU | MZUHFBTD |
| Weight | 1.000000 |
| selling_potential | 3 |
| With Built-in Battery | Yes |
