RFID UHF 860-960 MHz EPC Reader Writer Portable Desktop Bluetooth
GENERAL DESCRIPTION
UHFREADER816UBT is a high performance and portable ISO18000-6C (EPC C1G2) Protocol UHF tag reader. It is designed upon fully self-intellectual property and supports fast tag read/write operation with high identification rate. It can be widely applied in many RFID application systems such as stock management, traceability system, personnel identification, access control and anti-counterfeit system.
FEATURES
- l Fashion, thin and well portable design;
- l Ultra low power design, over 3 hours continuous reading tag and over 1 day in standby;
- l Support interactive and trigger-activating work mode;
- l Support ISO18000-6C (EPC C1G2) protocol tag;
- l 902~928MHz or 865~868MHz frequency band(frequency customization optional);
- l FHSS or Fix Frequency transmission;
- l Built-in TX/RX antenna with up to 1000mm effective distance*;
- l RF output power from 0 to 26dbm (adjustable) with RSSI supported;
- l Multiple tag anti-collision>50pcs/s, multiple tag inventory speed>50pcs/s;
- l Tag buffer size: 370PCS@Max.128bitsEPC or 120PCS@Max.496bitsEPC;
- l Support Bluetooth 4.0. Built-in lithium battery and no external power supply needed;
- l USB1.1 interface. Provide DLL and demonstration software to facilitate development;
- l Support USB charging and also the charging indicator, the low battery indicator;
CHARACTERISTICS
l Absolute Maximum Rating
|
ITEM |
SYMBOL |
VALUE |
UNIT |
|
Charging Voltage |
VCC |
6 |
V |
|
Operating Temp. |
TOPR |
-10~+70 |
℃ |
|
Storage Temp. |
TSTR |
-20~+85 |
℃ |
l Electrical Specification
|
ITEM |
SYMBOL |
MIN |
TYP |
MAX |
UNIT |
|
Charging Voltage |
VCC |
4.2 |
5 |
5.5 |
V |
|
Charging Current |
IBAT |
|
500 |
|
mA |
|
Standby Current |
ISTBY |
|
14 |
20 |
mA |
|
Continuous RF Current |
IRF |
|
100 |
200 |
mA |
|
Frequency |
FREQ |
902 |
|
928 |
MHz |
|
Effective Distance* |
DIS |
0 |
70 |
100 |
mm |
|
Size |
L×W×H |
|
110 × 50 × 5.8 |
|
mm |
* Effective distance depends on tag and working environment.
| Description | GENERAL DESCRIPTION UHFREADER816UBT is a high performance and portable ISO18000-6C (EPC C1G2) Protocol UHF tag reader. It is designed upon fully self-intellectual property and supports fast tag read/write operation with high identification rate. It can be widely applied in many RFID application systems such as stock management, traceability system, personnel identification, access control and anti-counterfeit system. FEATURES
CHARACTERISTICS l Absolute Maximum Rating
l Electrical Specification
* Effective distance depends on tag and working environment. |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SKU | HY9816UBT | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Weight | 0.500000 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| selling_potential | 3 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| With Built-in Battery | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Condition | New |
