WiFi 8 Inch Touch Screen MIFARE Card Reader Face Scanner for Access Control

SKU

WCAM101119340548

Be the first to review this product

Special Price US$189.05 Regular Price US$210.06

In stock

Overview

WiFi 8 Inch Touch Screen MIFARE Card Reader Face Scanner for Access Control

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

Model NO. : B2002FR-8I-UTS-RF-WM(WIFI)
Face Capacity : 24000+ Face
Record Capacitry : 160000 Face
Transport Package : Standard Package
Specification : 900g
Trademark : OEM
Origin : China
HS Code : 851769900
Production Capacity : 20000
Model : B2002FR-8I-UTS-RF-WM(WIFI)
Hardware :
Processor : Dual Core Processor+ 1G memory + 16G flash
Operating system : Linux Operating system
Sensor : 1/2.8" Progressive Scan CMOS
Lens : 4.5mm
WiFi module : 2.4GHz frequency band, IEEE802 b/g/n protocol;
5GHz frequency band, IEEE802 a/n/ac protocol
4G module (optional) : Support LTE-FDD, LTE-TDD, DC-HSPA+, WCDMA, EDGE, GPRS and other network standards, the maximum downlink rate is 160Mbps, and the maximum uplink rate is 60Mbps
Bluetooth module : GFSK, DQPSK, 8DPSK, LE (1Mbps), 2LE (2Mbps) technical specifications
Speaker : voice playback content can be customized
Performance :
Recognition height : 1.2~2.3 meters, angle adjustable
Recognition distance : 0.5~1.5 meters, depends on lens
Recognition angle : Vertical viewing angle: 30°; Horizontal viewing angle: 30°
Recognition time : Less than 0.3 seconds
Storage capacity : 160,000 capture records
Face capacity : 24,000pcs
Screen brightness : ≥400 cd/m2
Card type : Support reading 13.56MHz, 125KHz, 915MHz frequency band signals, the type of card reading includes Mifare, CPU card
Interface :
Power out : DC12V/2A
Network interface : 1 RJ45 10M / 100M adaptive Ethernet port,
Gigabit Ethernet port can be customized
Wiegand interface : 1ch Wiegand interface input/output
Alarm interface : 1ch alarm interface input
Door senor interface : 1ch magnetic interface input
Open interface : 1ch open door interface input
Doorbell interface : 1ch doorbell interface output
Lock interface : 1ch lock interface output
Communication interface : 1ch RS485 interface
Camera :
Camera : Dual cameras
Effective pixels : 2MP, 1920*1080
Min Illumination : Color 0.01Lux @F1.2(ICR);B/W 0.001Lux @F1.2 (ICR)
SNR : ≥50db(AGC OFF)
WDR : 120db, ISP algorithm face partial exposure
Resolution : Main Stream
Sub Stream : 704*576, 1-25 frames/second, 640*480, 1-25 frames/second, 352*288, 1-25 frames/second
Function :
Web side configuration : support
Remote upgrade : support
Regular :
Operating temperature : -10ºC - +55ºC
Working humidity : 0~90% relative humidity, no condensation
Salt spray : level Rp6 or above
Antistatic : contact ±6KV, air ±8KV
Power : DC12V/2A
Waterproof : IP42
Power : 20W(MAX)
Equipment size : 215.22 (L) * 130 (W) * 15 (T) mm
Screen size : 8 inches IPS HD screen
