High Accuracy 140dB WDR Water-Proof Nigth Version Vehicle Plates Recogntion Camera

Model : Surveillance

• Sensor : CMOS
• Kind : Motorized Lens
• Technology : Infrared
• Horizontal Resolution : 650tvl
• Name : Lpr Camera
• IR Distance : 50m
• SIP : Supports
• Power : Poe (802.3af) / DC 12V± 10%
• Lens : Motorized 2.7~13.5mm/3.0~10.5mm/[email protected] P-Iris
• Protocol : Rtsp, Rtmp, HTTP, Https, DNS, DDNS, DHCP, FTP, Ntp
• Transport Package : Carton Box
• Specification : 76mmX239.5mm
• Trademark : OEM
• Origin : China
• HS Code : 8525801390
• Production Capacity : 10000PCS/Month
• Camera : Model Image Sensor : 1/2.8″ Progressive Scan CMOS
  Min. Illumination : Color: [email protected] F1.2Color: [email protected] F1.4B/W: 0Lux with IR on
• WDR : 140dB Super WDR
• Shutter Time : 1/ 100000s~1s
• IR Distance : Up to 50m
  Day/ Night Mode : Day/Night/Auto/Customize/Schedule S/ N : >55dB
• Lens :Lens Field of View : H111°~H34°/ D130°~D39°/V60°~V19°(2.7~13.5mm)H100°~H33°/ D115°~D38°/V54°~V18°(3~10.5mm)H42°~H17°/ D48°~D19°/V24°~V9°(7~22mm)
• Mount : Φ14
• Focus Control : Auto/ Manual
  Iris Control  (Optional for I Series) : Auto/ Manual
• LPR : Max. Vehicle Speed
• Recognition Accuracy : >95%
  Coverage : Support simultaneous detection of 4 regions
  White/ Black List : Up to 1000 records inside the camera
  Smart Traffic Detection : License Plate Recognition, Plate Type Classification, Plate Color Recognition, Vehicle Type Classification, Vehicle ColorRecognition, Vehicle Direction Detection
• Video : Max. Image Resolution
• Primary Stream : 60HZ: [email protected](1920x1080, 1280x960, 1280x720, 704x576)50Hz: [email protected](1920x1080, 1280x960, 1280x720, 704x576)
  Secondary Stream : 60Hz: [email protected](704x576, 640x480, 640x360, 352x288, 320x240, 320x192, 320x180)50Hz: [email protected](704x576, 640x480, 640x360, 352x288, 320x240, 320x192, 320x180)
• Tertiary Stream : 60Hz: [email protected](1920x1080,50Hz: [email protected](1920x1080,
  Video Compression : H.265+/H.265( HEVC)/H.264+/ H.264/ MJPEG
• Video Bit Rate : 16Kbps~16Mbps(CBR/VBR Adjustable)
  Privacy Masking : Up to 28 areas(24 mask areas and 4 mosaic areas)
• ROI : Up to 8 areas
  Image Setting : Brightness/Contrast/Saturation/Sharpness
