4.3 Inch Touch Screen Wireless NFC Card Blue Tooth Mutiple Interfaces Face Scan Reader

4.3'' Touch Screen Face Recognition Access Control Terminal

• Main Features:Support real-time
  live detection
• Support for human face tracking exposure in strong backlight
• Unique live face recognition algorithm to accurately recognize faces, face recognition time is less than 0.5s
• Using Linux operating system, better system stability
• Meantime between failures MTBF>50000H
• Support:TCP/IP,UDP,DNS,DHCP
• protocolSupport24,000+ face matching library and
  60,000 face recognition records
• Operating temperature: -20ºC-+55ºC
• Outdoor IP42waterproof and dustproof
• Support:tamper alarm
• Support microphone input audio, speaker output audio
  Rich hardware interface(I/O, WG26, WG34, RJ45, Door
  senor, Doorbell, Open door, Alarm, RS485)
• 3-inch capacitance multi-touch screen, nostreaking, anddelay



Specifications:

1. Model:B2002FR-4I-RF-WF-WM-E
   Hardware:Processor Dual-Core ARM Cortex-A7, @1.0GHz
2. Operating system:Linux Operating system
3. Sensor:1/2.8" Progressive Scan CMOS
4. Lens:4.5mm
5. Card swiping module:(Optional)
   Support reading:13.56MHz, 125KHz, 915MHz frequency band signals, the type of card reading includes Mifare, CPU card
   WiFi module IEEE 802.11b/g/n standard, support 2.4GHz frequency band, speed range 1Mbps-150Mbps
6. Touch screen:Support, capacitance multi-touch screen
   Speaker:Voice playback content can be customized
7. Performance:Recognition
8. Height:1.2~2.2meters, angle adjustable
   Recognition distance0.3~1.5meters
9. Viewing angle:Vertical viewing angle: 30°, horizontal viewing angle: 30°
   Recognition time Less than 0.5seconds
10. Storage capacity:60,000 capture records
11. Network interface
    1 RJ45 10M / 100M adaptive Ethernet port, Gigabit Ethernet port can be customized
    Wiegand interface
    Dual cameras Effective pixels 2MP,1920*1080Min Illumination
    Color 0.01Lux @F1.2(ICR);B/W 0.001Lux @F1.2 (ICR)SNR≥50db(AGC OFF)
    Screen
    Operating temperature:-20ºC - +55ºC
    Working humidity:0~90%
    relative humidity, no condensation
    Salt spray:Level Rp6 or above
    Antistatic Contact ±6KV, air ±8KV

    FAQ
    who are we?
    We are based in Guangdong, China, start from 2010,sell to North America(50.00%),Eastern Europe(20.00%),Northern Europe(10.00%),Western Europe(10.00%),Southern Europe(5.00%).
    2. how can we guarantee the quality?
    Always a pre-production sample before mass production;
    Always final Inspection before shipment;
    3.what can you buy from us?
    IP Video Intercom,video door phone,sip intercom,face capture camera,face recognition terminal
    4. why should you buy from us, not from other suppliers?
    14 years experience only about face recognition IP surveillance SIP intercom camera Design and manufacturer, innovation and stably quality is our aim worked for. 1. provide SDK &API Command to customize; 2.developed own face recognition algorithm
    5. what services can we provide?
    Accepted Delivery Terms: FOB,CIF,EXW,CIP,DDP,DDU,Express Delivery;
    Accepted Payment Currency:USD,EUR,HKD,CNY;
    Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
    Language Spoken: English, Chinese
    Our Free Software



Packing and Contact Details
Model NO. : B2002FR-4I-UTS-RF-WM(WIFI)
RFID : 13.56MHz
Face Capacity : 24000+
Screen : 4.3 Inch Touch Screen
WiFi : Supports
Face Access Speed : 0.3s
Transport Package : Carton Box
Specification : 0.5kg
Trademark : OEM
Origin : China
HS Code : 8543709990
Production Capacity : 5000PCS
Model : B2002FR-4I-RF-WF-WM-E
Hardware :
Processor : Dual-Core ARM Cortex-A7, @1.0GHz
Operating system : Linux Operating system
Sensor : 1/2.8" Progressive Scan CMOS
Lens : 4.5mm
Card swiping module(Optional) : Support reading 13.56MHz, 125KHz, 915MHz frequency band signals, the type of card reading includes Mifare, CPU card
WiFi module : IEEE 802.11b/g/n standard, support 2.4GHz frequency band, speed range 1Mbps-150Mbps
Touch screen : Support, capacitance multi-touch screen
Speaker : Voice playback content can be customized
Performance :
Recognition height : 1.2~2.2 meters, angle adjustable
Recognition distance : 0.3~1.5 meters
Viewing angle : Vertical viewing angle: 30°, horizontal viewing angle: 30°
Recognition time : Less than 0.5 seconds
Storage capacity : 60,000 capture records
Face capacity : 24,000pcs
Network interface : 1 RJ45 10M / 100M adaptive Ethernet port, Gigabit Ethernet port can be customized
Wiegand interface : 1ch Wiegand interface input/output
Alarm interface : 1ch alarm interface
Door senor interface : 1ch magnetic interface
Open interface : 1ch open door interface
Doorbell interface : 1ch doorbell interface
Lock interface : 1ch lock interface
Communication interface : 1ch RS485 interface
Camera :
Camera : Dual cameras
Effective pixels : 2MP, 1920*1080
Min Illumination : Color 0.01Lux @F1.2(ICR);B/W 0.001Lux @F1.2 (ICR)
SNR : ≥50db(AGC OFF)
Screen resolution : 480*272
Regular :
Operating temperature : -20ºC - +55ºC
Working humidity : 0~90% relative humidity, no condensation
Salt spray : Level Rp6 or above
Antistatic : Contact ±6KV, air ±8KV
Power : DC12V/2A
Waterproof : IP42
Power : 10W(MAX)
Equipment size : 160(L) * 88 (W) * 17(T) mm
Screen size : 4.3-inch capacitance multi-touch screen
